AOK-100WHBA
AOK
##
PRODUCT OVERVIEW
The HBA series features the impressive 100W Industrial High Bay LED Lighting solution. This advanced lighting system is designed to provide outstanding performance and efficiency, making it ideal for indoor and industrial environments. Its unique optical design effectively reduces glare while maximizing light output. Whether you need lighting for gyms, schools, churches, retail spaces, sports halls, warehouses, or factories, the HBA series offers a variety of distributions to meet your specific requirements. Experience the benefits of high-quality lighting with the HBA series and elevate the illumination in your space.
ELECTRICAL/LED
• Patented design
• System efficiency 160 lm/W ,210lm/W optional
• High efficiency driver, PF > 0.95
• Lumileds 2835 LED light source, CRI: 80
• ADC12 aluminum die casting housing , perfect heat dissipation
• Available with 60°/ 90°/120° beam angle
• 3000K / 4000K / 5000K / 5700K / 6500K CCT
• Long life span , L90B10 > 52,000 Hours
MOUNTING/ACCESSORIES
Hook/Yoke/Chain mounts
RECOMMENDED USE
● Manufacturing facilities
● Warehouses and storage areas
● Sports and recreational facilities
● Convention centers and exhibit halls
● Big-box stores and shopping malls
● Passenger terminals
● Airport hangars
● Classified areas
● Repair shops & garage
● Hose down areas
WARRANTY
5-year standard warranty, 10-year warranty optional. Please consult with AOK sales for detailed agreement.
DIMENSION
PRODUCT OVERVIEW
The HBA series features the impressive 100W Industrial High Bay LED Lighting solution. This advanced lighting system is designed to provide outstanding performance and efficiency, making it ideal for indoor and industrial environments. Its unique optical design effectively reduces glare while maximizing light output. Whether you need lighting for gyms, schools, churches, retail spaces, sports halls, warehouses, or factories, the HBA series offers a variety of distributions to meet your specific requirements. Experience the benefits of high-quality lighting with the HBA series and elevate the illumination in your space.
ELECTRICAL/LED
• Patented design
• System efficiency 160 lm/W ,210lm/W optional
• High efficiency driver, PF > 0.95
• Lumileds 2835 LED light source, CRI: 80
• ADC12 aluminum die casting housing , perfect heat dissipation
• Available with 60°/ 90°/120° beam angle
• 3000K / 4000K / 5000K / 5700K / 6500K CCT
• Long life span , L90B10 > 52,000 Hours
MOUNTING/ACCESSORIES
Hook/Yoke/Chain mounts
RECOMMENDED USE
● Manufacturing facilities
● Warehouses and storage areas
● Sports and recreational facilities
● Convention centers and exhibit halls
● Big-box stores and shopping malls
● Passenger terminals
● Airport hangars
● Classified areas
● Repair shops & garage
● Hose down areas
WARRANTY
5-year standard warranty, 10-year warranty optional. Please consult with AOK sales for detailed agreement.
DIMENSION
Electrical Data | |||
Model | AOK-HBA100 | AOK-HBA150 | AOK-HBA200 |
Power(W) | 100W | 150W | 200W |
Input voltage | Normal Voltage=100-277VAC, High Voltage=277-480VAC, please read *Note-1 before choosing. | ||
THD | <20% | ||
PF | >0.95 | ||
Control Option | 0-10V, PWM, Resistor, AUX: 12V/0.15A. Occupancy and motion sensor, DALI control optional. | ||
Operating temperature | -40°C to 45°C (-40 °F to 113 °F) | ||
Photometric Data | |||
Efficacy(lm/W, Std. Dev ±5%) | 160lm/W (Please refer to IES for exact data) | ||
Luminous flux (lm, Std. Dev ±5%) | 16000lm | 24000lm | 32000lm |
Efficacy(lm/W, Std. Dev ±5%) | 200lm/W~210lm/W (Please refer to IES for exact data) | ||
Luminous flux (lm, Std. Dev ±5%) | 20000lm | 30000lm | 40000lm |
ULOR | = 0%, @ Luminaire inclination 0° | ||
CCT | 3000K, 4000K, 5000K, 5700K, 6500K | ||
CRI | Ra80 | ||
Beam angle | 60D/90D/120D | ||
LED Manufacturer | Lumileds | ||
LED model | 2835 | ||
Lens | Polycarbonate (Better impact resistance than glass) | ||
Mechanical Data | |||
IP/IK | IP65/IK09, according to standard EN 60529 and EN 62262 | ||
Housing/Materials | Heavy-duty die-cast aluminum (ADC12) | ||
Surface treatment | Anti-UV thermosetting polyester (for extremely corrosive environments). | ||
Painting | Black, Custom on request | ||
Cable | Pre-wired with a 30 cm cable (Other lengths on request) | ||
Mounting | Hook | ||
Others | |||
Lifespan | L90B10 > 52000hrs, @Ta 25°C | ||
Warranty | 5 years (Warranty extension up to 10 years on request) | ||
Certification | UL/cUL/FCC/ROHS/CE/SAA,/For other certificates please request | ||
Product size | Ø278*189.1mm / Ø10.9*7.4 inches | Ø320*189.1mm / Ø12.6*7.4 inches | Ø360*196.2mm Ø10.9*7.7 inches |
Net weight | 1.72kg / 3.79 lbs | 2.14kg / 4.72 lbs | 2.64kg / 5.82 lbs |
Carton size | 300*300*160mm / 11.8*11.8*6.3 inches | 350*350*165mm / 13.8*13.8*6.5 inches | 390*390*170mm / 15.4*15.4*6.7 inches |
Gross weight | 2.18kg / 4.81 lbs | 2.72kg / 5.60 lbs | 3.36kg / 7.41 lbs |
QTY./CTN. | 1 PCS/CTN | 1 PCS/CTN | 1 PCS/CTN |
Important note! | The provided information is solely for reference; the official measurement report holds higher authority. |
Electrical Data | |||
Model | AOK-HBA100 | AOK-HBA150 | AOK-HBA200 |
Power(W) | 100W | 150W | 200W |
Input voltage | Normal Voltage=100-277VAC, High Voltage=277-480VAC, please read *Note-1 before choosing. | ||
THD | <20% | ||
PF | >0.95 | ||
Control Option | 0-10V, PWM, Resistor, AUX: 12V/0.15A. Occupancy and motion sensor, DALI control optional. | ||
Operating temperature | -40°C to 45°C (-40 °F to 113 °F) | ||
Photometric Data | |||
Efficacy(lm/W, Std. Dev ±5%) | 160lm/W (Please refer to IES for exact data) | ||
Luminous flux (lm, Std. Dev ±5%) | 16000lm | 24000lm | 32000lm |
Efficacy(lm/W, Std. Dev ±5%) | 200lm/W~210lm/W (Please refer to IES for exact data) | ||
Luminous flux (lm, Std. Dev ±5%) | 20000lm | 30000lm | 40000lm |
ULOR | = 0%, @ Luminaire inclination 0° | ||
CCT | 3000K, 4000K, 5000K, 5700K, 6500K | ||
CRI | Ra80 | ||
Beam angle | 60D/90D/120D | ||
LED Manufacturer | Lumileds | ||
LED model | 2835 | ||
Lens | Polycarbonate (Better impact resistance than glass) | ||
Mechanical Data | |||
IP/IK | IP65/IK09, according to standard EN 60529 and EN 62262 | ||
Housing/Materials | Heavy-duty die-cast aluminum (ADC12) | ||
Surface treatment | Anti-UV thermosetting polyester (for extremely corrosive environments). | ||
Painting | Black, Custom on request | ||
Cable | Pre-wired with a 30 cm cable (Other lengths on request) | ||
Mounting | Hook | ||
Others | |||
Lifespan | L90B10 > 52000hrs, @Ta 25°C | ||
Warranty | 5 years (Warranty extension up to 10 years on request) | ||
Certification | UL/cUL/FCC/ROHS/CE/SAA,/For other certificates please request | ||
Product size | Ø278*189.1mm / Ø10.9*7.4 inches | Ø320*189.1mm / Ø12.6*7.4 inches | Ø360*196.2mm Ø10.9*7.7 inches |
Net weight | 1.72kg / 3.79 lbs | 2.14kg / 4.72 lbs | 2.64kg / 5.82 lbs |
Carton size | 300*300*160mm / 11.8*11.8*6.3 inches | 350*350*165mm / 13.8*13.8*6.5 inches | 390*390*170mm / 15.4*15.4*6.7 inches |
Gross weight | 2.18kg / 4.81 lbs | 2.72kg / 5.60 lbs | 3.36kg / 7.41 lbs |
QTY./CTN. | 1 PCS/CTN | 1 PCS/CTN | 1 PCS/CTN |
Important note! | The provided information is solely for reference; the official measurement report holds higher authority. |
